$289.00 USD
Shipping calculated at checkout.
Conergies TPU Azure Golden (S1108)is a standout model in the CONERGIES ColorPPF Satin Series, delivering rich purple tones with vibrant depth and a high-gloss, paint-like finish. Engineered with hydrophilic TPU and dual Grade-8 UV-protected color layers, it ensures long-lasting color stability, smooth clarity, and a clean OEM-style appearance while providing reliable paint protection.
Storage Guidelines
Product Name
TPU Azure Golden (S1108)
Recommended Storage Temperature
15–25°C (59–77°F)
Recommended Storage Humidity
45–50%
Storage Environment
Store in a clean, indoor environment, free from excessive or visible dust and airborne particles.
-
All products must be stored in their original packaging and protected by the original protective materials.
-
It is recommended to store rolls in a sealed, vertical position, away from direct sunlight and heat sources.
-
After opening, remove the surface protection layer from any remaining film to prevent issues such as warping or fogging.
-
Strict control of temperature and humidity is essential to maintain product performance and stability.
-
Products must be stored and installed in accordance with the specified guidelines to ensure long term durability.
-
Warranty coverage is valid only when all usage, storage, and maintenance guidelines are properly followed.
PHYSICAL PERFORMANCE INDICATORS
|
Property
|
Specification
|
Standard / Reference
|
|
Gloss
|
≥ 90°
|
GB 8807
|
|
Weight (Finished Product)
|
355–395 g/m²
|
GB/T 4669
|
|
Weight (Adhesive)
|
25–30 g/m²
|
GB/T 4669
|
|
Overall Thickness
|
183.88–208.13 µm
|
GB/T 7125
|
|
Thickness (Removable PET Layer)
|
45–55 µm
|
GB/T 7125
|
|
HOC Top Coating Thickness
|
9.5–10.5 µm
|
GB/T 7125
|
|
Aliphatic TPU Film (> UV90 Protection)
|
57–63 µm
|
GB/T 7125
|
|
Grade 8 UV Protection Top Color Layer
|
16.63–18.38 µm
|
GB/T 7125
|
|
Grade 8 UV Protection Base Color Layer
|
10.5–16.5 µm
|
GB/T 7125
|
|
Aliphatic TPU Base Film
|
57–63 µm
|
GB/T 7125
|
|
Adhesive Thickness
|
33.25–36.75 µm
|
GB/T 7125
|
|
Thickness (PET Liner)
|
75–85 µm
|
GB/T 7125
|
|
Break Elongation (HOC Layer, MD)
|
≥ 60%
|
GB/T 1040.1
|
|
Dimensional Stability (MD)
|
≤ 0.5 mm
|
FTM 14
|
|
Dimensional Stability (CD)
|
≤ 0.4 mm
|
FTM 14
|
|
Peel Force (Finished Product)
|
≤ 0.3 N/25 mm
|
GB/T 2792
|
|
Initial Adhesion
|
≥ 8 N/25 mm
|
FTM 9
|
|
24 h 180° Peel Force
|
≥ 12 N/25 mm
|
GB/T 2792
|
|
Storage Aging Peel Force
|
≥ 10 N/25 mm
|
GB/T 2792
|
|
Application Aging Peel Force
|
≥ 16 N/25 mm
|
GB/T 2792
|
